Whirlpool W11512152 Refrigerator Ice Maker Assembly

Whirlpool W11512152 Refrigerator Ice Maker Assembly

Genuine Whirlpool refrigerator ice maker assembly for supported models. Replaces the ice-making unit when the assembly itself is the confirmed cause of missing or irregular ice production.

Replacement references: W10300023, WPW10300023, W10272870, W10122555. Confirm the replacement against your appliance model before ordering.

Will this fit my appliance? Use the full appliance model to confirm the replacement chain. Check the electrical connector, mounting and ice maker location; W11512149 and W11512152 are different service parts despite their similar numbers.

Before replacing the ice maker: Confirm the ice maker is enabled, the water supply is available and the freezer is cooling correctly. No ice or small cubes can also result from a restricted filter, water valve or fill tube; those symptoms alone do not prove the assembly has failed.

How to find your model number: Look for the rating label inside the refrigerator or freezer compartment, often on a side wall or door frame. Copy the full model number, including its suffix. If you are unsure, contact us with that information before ordering.
