Whirlpool Black Cooktop Burner Cap Set of 5 - W10832694

Whirlpool Black Cooktop Burner Cap Set of 5 - W10832694

Whirlpool W10832694 is a genuine OEM set of five black gas cooktop burner caps. The caps cover the matching burner heads, help distribute the flame, and replace missing or damaged caps across the compatible cooktop.

Fitment: Model examples include Whirlpool WCG51US6DB00 and Maytag MGC7536DB00. Examples are not a complete fit list. Confirm the complete model and five-cap arrangement before ordering; burner bases and electrodes are not part of this set.

Legacy and replacement numbers: W10832694 replaces Whirlpool burner cap set W10597133.

Is it time to replace?

Replace a missing, chipped, cracked, or warped cap that will not sit correctly. For an uneven flame or poor ignition, first clean, fully dry, and reseat the correct cap as directed in the appliance manual. Install only after the cooking surface is cool.

How to find your model number
Check the rating label on the underside of the cooktop; its location varies by model. Use the full model number and final suffix to match the burner diagram.

Technical Specifications
