Frigidaire Dishwasher Upper Spray Arm - 5304506516

Frigidaire Dishwasher Upper Spray Arm - 5304506516

Restore upper-rack wash coverage with this genuine OEM Frigidaire Dishwasher Upper Spray Arm - 5304506516. This upper spray arm rotates and sprays water across the upper rack so cups, glasses, and small dishes receive proper wash coverage.

5304506516 is an upper spray arm used on compatible Frigidaire-built dishwashers. Source listings identify it as a gray plastic upper spray arm that can often be replaced without tools after removing the rack stops, upper rack, mount, and spray arm as needed.

Compatibility: Fits select Frigidaire, Crosley, Kenmore/Sears, Kelvinator, Ikea, and related Electrolux-family dishwasher platforms where the model lookup calls for 5304506516.

Fitment Families: Upper-rack spray arm family. Exact fit depends on upper rack/wash-tube design, mounting hub, water-feed connection, rack stop style, and whether the related mount/support is serviceable.

This part commonly cross-references or replaces previous/service part numbers including 154478201, 154478202, 154607802, 154698901, 154698902, 154754502, AP6036336, PS11770483, 4456334.

Fitment / What To Verify: Verify full dishwasher model number, upper vs lower location, mounting hub, feed-tube connection, color/style, and whether the spray arm mount/support is included or must be reused. Do not substitute a lower arm for an upper arm.

Please confirm fitment with your appliance model number before ordering.

Is it time to replace?

• Common Symptoms: Upper rack dishes not cleaning, spray arm not rotating, noisy wash action, water spraying incorrectly, leaks, or poor drying caused by weak upper wash coverage.
• Visible/Sensory Cues: Cracked plastic, melted or distorted spray holes, broken hub, mineral-clogged nozzles, arm binding on rack, or missing retaining hardware.

Pro Tip: Before replacing, clear mineral buildup from the feed tube and confirm the arm spins freely. A blocked feed path can mimic a failed spray arm.

Technical Specifications

Legacy part number(s)/code(s): 154754502, 154607802, 154698901
